Don-Jo 1517 Floor Door Holder
The Don-Jo 1517 is a floor-mounted door holder in brass: a cast pedestal on the floor engages a strike on the door to hold it open, and releases with a pull.
Floor-mounted holders are chosen by the measured gap between the door bottom and the floor — Don-Jo 1520 through 1523 cover the standard bands; confirm this model's fit against your clearance. Measure the clearance before ordering. It is a mechanical holder, not an alarm-released hold-open.
Specification highlights
- Brass, 3-1/2" high.
- ANSI/BHMA A156.16 L11241.
- Fasteners supplied for the mounting shown in the specification table.
Ordering notes
Order as number + finish. A stop limits the swing; a holder holds the door open — do not substitute one for the other on a schedule. This item is made to order.
Technical Specifications
| Model | Don-Jo 1517 |
| Type | Floor Door Holder |
| Material | Brass |
| Height | 3-1/2" |
| Mounting | Floor-mounted pedestal with door-mounted strike |
| ANSI/BHMA | A156.16 — L11241 |
| Fasteners Supplied | 2 ea. Plastic Anchors, 1 each 1/2-13 X 3-1/4" Stud. 1 ea. Lead Anchor. 2 ea 1/4" FHSMS, 1 ea. 1/4-20 1-1/4" FHSMS, 1 ea Lead Anchor |
| Finishes Carried | 626 |
| Lead Time | 3–10 business days (made to order) |
| Brand | Don-Jo |
| General - US Finishes | US26D - Satin Chrome |
| Height | 3-1/2 inch |
