Hager 9630CS Commercial Pocket Door Kit — 84" Track for 3'0" Door
The Hager 9630CS is a complete, industrial-grade sliding door hardware system for concealed pocket-door openings in commercial, healthcare, multi-family, and hospitality construction. Part of the Hager 9600 Commercial Series, the 9630CS is engineered for a 3'0" (914 mm) wide door up to 7'0" (2134 mm) tall and supports doors weighing up to 150 lbs. (68 kg). The 84-inch kit length provides the track span required for a full 7'0" pocket door opening, delivering smooth, quiet, space-saving operation without a swinging door arc.
At the heart of the kit is the Hager 9303HD extruded aluminum jump-proof track, whose precision "V" rail geometry keeps the four-wheel hangers positively seated during every cycle — eliminating the derailment risk common on lighter residential pocket door hardware. The included 2x4 commercial pocket frame with split studs maintains wall integrity and pocket clearance, protecting the door finish over years of high-frequency use.
Key Features & Benefits
- 150 lb Door Capacity: Rated for commercial pocket doors up to 150 lbs. (68 kg) — suitable for solid-core wood and light hollow metal doors.
- Jump-Proof 9303HD Track: Extruded aluminum construction with precision "V" rails for silent, derailment-resistant travel even in high-traffic applications.
- Complete 2x4 Commercial Kit: Includes pocket frame, split studs, 9805 four-wheel hangers, and floor guide — everything needed for a full rough-in installation.
- BHMA Grade 1 Certified: Meets ANSI/BHMA A156.14 by exceeding 100,000 operational cycles — the commercial specification standard for pocket door hardware.
- 84" Kit Length: Correctly sized for a 3'0" door up to 7'0" (2134 mm) in height.
- Soft-Close Compatible: Accepts the Hager 1-269-8651 soft-close accessory (sold separately) for doors up to 150 lbs.
Applications
- Commercial office tenant improvements and conference room entries
- Healthcare corridor doors, patient room entries, and exam room openings
- Hospitality and multi-family unit doors where swing clearance is limited
- ADA-accessible openings benefiting from a pocket door configuration
Technical Details
| Feature | Details |
|---|---|
| Model Number | Hager 9630CS |
| Series | 9600 Commercial Series Pocket Door Frame Kit |
| Track Model | 9303HD — Extruded Aluminum, Jump-Proof "V" Rail |
| Hanger | 9805 (4-wheel) |
| Kit Length | 84 Inches |
| Max Door Weight | 150 lbs. (68 kg) |
| Door Width | 3'0" (914 mm) |
| Door Height | Up to 7'0" (2134 mm) |
| Frame Included | 2x4 Commercial Pocket Frame with Split Studs |
| Certification | ANSI/BHMA A156.14 Grade 1 (100,000+ cycles) |
| Finish | Mill Aluminum (MIL) |
| Soft-Close Compatible | Yes — Hager 1-269-8651 (sold separately, doors up to 150 lbs.) |
9600 Commercial Series — Available Kit Sizes for 3'0" Door
The Hager 9600 CS pocket door kit series is available in four kit lengths to match the door height. All sizes are for a 3'0" wide door:
- 9631CS: 80" kit — for a 6'8" door
- 9630CS: 84" kit — for a 7'0" door
- 9629CS: 96" kit — for an 8'0" door
- 9628CS: 108" kit — for a 9'0" door
For doors exceeding 150 lbs., consider the Hager 9850HD or 9852HD series, rated for 250 lbs.
| Brand | Hager |
| Length | 84 Inch |
| Trackset Type | Pocket Door |
| Maximum Weight of Door | 150 Lbs |
