Hager 9629CS Commercial Pocket Door Kit — 96" Track for 3'0" Door, 150 lb Capacity
The Hager 9629CS is a complete, commercial-grade pocket door hardware kit engineered for a 3'0" (914 mm) wide door up to 8'0" (2438 mm) tall, supporting doors weighing up to 150 lbs. (68 kg). Part of the Hager 9600 Commercial Series, the 9629CS ships as a full 2x4 commercial pocket frame assembly — track, hangers, split studs, and floor guide included — making it a single-source solution for concealed sliding door openings in commercial, healthcare, multi-family, and hospitality construction.
At the core of the kit is the Hager 9303HD extruded aluminum track, featuring precision "V" rail geometry that keeps the four-wheel hangers seated during high-frequency use for a quiet, jump-proof glide. The included split-stud pocket frame maintains wall integrity and protects the door finish over years of daily service.
Key Features & Benefits
- BHMA Grade 1 Certified: Meets ANSI/BHMA A156.14 by exceeding 100,000 operational cycles — rated for commercial specification work.
- 150 lb Door Capacity: Supports commercial pocket doors up to 150 lbs. (68 kg); step up to the 9850HD or 9852HD series for heavier doors up to 250 lbs.
- Jump-Proof 9303HD Track: Extruded aluminum with "V" rail geometry prevents hanger disengagement under load or high-traffic use.
- Complete Commercial Kit: Includes the 9303HD track, 9805 four-wheel hangers, 2x4 commercial pocket frame with split studs, and floor guide — everything needed for a full installation.
- Sized for 3'0" Door at 8'0" Height: 96" kit length accommodates standard commercial tall-door openings.
- Soft-Close Compatible: Works with the optional Hager 1-269-8651 soft-close accessory for doors up to 150 lbs.
- Mill Aluminum Finish: Corrosion-resistant extruded aluminum track suited for concealed pocket frame installation.
Typical Applications
- Commercial office and tenant-improvement buildouts
- Healthcare and medical office facilities
- Multi-family residential corridors and unit entries
- Hospitality and hotel guest room openings
- Any application where swing clearance is limited and a space-saving sliding door solution is required
9600 Commercial Series — Available Kit Sizes for 3'0" Door
The Hager 9600 CS pocket door kit series supports a 3'0" wide door across multiple door heights:
- 9631CS: 80" kit — for a 6'8" door
- 9630CS: 84" kit — for a 7'0" door
- 9629CS: 96" kit — for an 8'0" door (this listing)
- 9628CS: 108" kit — for a 9'0" door
Technical Details
| Feature | Details |
|---|---|
| Model Number | Hager 9629CS |
| Series | 9600 Commercial Series Pocket Door Frame Kit |
| Track Model | 9303HD — Extruded Aluminum, Jump-Proof "V" Rail |
| Hanger Model | 9805 — 4-Wheel Hanger |
| Kit Length | 96 Inch |
| Door Width | 3'0" (914 mm) |
| Door Height (Max) | 8'0" (2438 mm) |
| Maximum Door Weight | 150 lbs. (68 kg) |
| Frame Type | 2x4 Commercial Pocket Frame with Split Studs |
| Certification | ANSI/BHMA A156.14 Grade 1 (100,000+ cycles) |
| Finish | MIL (Mill Aluminum) |
| Soft-Close Compatible | Yes — Hager 1-269-8651 (doors up to 150 lbs.) |
| Trackset Type | Pocket Door |
| Brand | Hager |
| Length | 96 Inch |
| Trackset Type | Pocket Door |
| Maximum Weight of Door | 150 Lbs |
