Hager 9631CS Commercial Pocket Door Kit — 80" Track for 3'0" Door, 150 lb Capacity
The Hager 9631CS is a complete, heavy-duty commercial pocket door hardware kit engineered for a 3'0" (914 mm) wide door up to 6'8" (2032 mm) tall, with a door weight capacity of up to 150 lbs. (68 kg). Part of the Hager 9600 Commercial Series, this kit delivers everything needed for a concealed sliding pocket door installation in commercial, healthcare, multi-family, and hospitality construction — track, hangers, frame, and split studs included.
At the heart of the system is the Hager 9303HD extruded aluminum track, featuring precision-machined “V” rail geometry that keeps the four-wheel hangers seated and running smoothly even under high-frequency daily use. The integrated 2x4 commercial pocket frame with split studs maintains wall integrity and protects door finish over years of heavy cycling.
Key Features & Benefits
- ANSI/BHMA A156.14 Grade 1 Certified: Exceeds 100,000 operational cycles — meets the threshold for commercial specification work.
- 150 lb Door Capacity: Supports commercial pocket doors up to 150 lbs. (68 kg); for heavier doors, see the Hager 9850HD / 9852HD (250 lb) series.
- 9303HD Jump-Proof Track: Extruded aluminum with “V” rail precision geometry prevents hanger disengagement and provides quiet, low-effort travel.
- Complete Kit: Includes the 9303HD track, 9805 four-wheel hangers, 2x4 commercial pocket frame, split studs, and floor guide — no separate sourcing required.
- Soft-Close Compatible: Works with the optional Hager 1-269-8651 soft-close accessory (sold separately) for doors up to 150 lbs.
- Mill Aluminum Finish: Low-maintenance MIL finish suited for concealed rough-in installation.
Applications
- Commercial office buildouts and tenant improvements
- Healthcare and medical office facilities
- Hospitality and multi-family residential
- Any application requiring space-saving, concealed sliding door hardware rated for commercial use
Technical Details
| Feature | Details |
|---|---|
| Model Number | Hager 9631CS |
| Series | 9600 Commercial Series Pocket Door Frame Kit |
| Track Model | 9303HD — Extruded Aluminum, “V” Rail, Jump-Proof |
| Hanger Model | 9805 — 4-Wheel |
| Kit Length | 80 Inches |
| Door Width | 3'0" (914 mm) |
| Door Height | Up to 6'8" (2032 mm) |
| Door Thickness | 1-3/8" to 1-3/4" (35–44 mm) |
| Maximum Door Weight | 150 lbs. (68 kg) |
| Frame | 2x4 Commercial Pocket, Split Studs Included |
| Finish | MIL (Mill Aluminum) |
| Certification | ANSI/BHMA A156.14 Grade 1 (>100,000 cycles) |
| Soft-Close Compatible | Yes — Hager 1-269-8651 (sold separately, doors up to 150 lbs.) |
9600 Commercial Series — Available Kit Sizes for 3'0" Door
The Hager CS commercial pocket door kit is available in multiple track lengths to match door height. All models accommodate a 3'0" wide door:
- 9631CS — 80" kit for a 6'8" door
- 9630CS — 84" kit for a 7'0" door
- 9629CS — 96" kit for an 8'0" door
- 9628CS — 108" kit for a 9'0" door
| Brand | Hager |
| Length | 80 Inch |
| Trackset Type | Pocket Door |
| Maximum Weight of Door | 150 Lbs |
