Pemko 307BSPV Door Bottom Sweep — 7/8" Aluminum Channel with 1" Vinyl Insert, Black Suede Powder Coat
The Pemko 307BSPV is a commercial-grade door bottom sweep featuring a 7/8" aluminum channel paired with a 1" replaceable vinyl insert, finished in Black Suede Powder (BSP). Designed for commercial door openings, this door bottom seal delivers consistent draft, dust, and light-gap control along the bottom edge of the door. The 307BSPV is sold by the foot and cut to the stocked lengths shown, making it a versatile solution for a wide range of door widths. The vinyl insert is fully field-replaceable, extending the service life of the aluminum carrier and reducing long-term maintenance costs.
Institutional Grade Features & Benefits
- Replaceable Vinyl Insert: The 1" vinyl sweep insert can be swapped out without replacing the entire aluminum channel, reducing material waste and lowering lifecycle cost on high-use commercial doors.
- 7/8" Aluminum Channel Body: The extruded aluminum carrier provides a rigid, durable mounting base that resists warping, corrosion, and the repeated mechanical stress typical of commercial door applications.
- Black Suede Powder Coat Finish (BSP): The Black Suede Powder finish delivers a professional, low-sheen appearance that coordinates with dark door hardware and frames while providing additional corrosion resistance to the aluminum channel.
- Sold by the Foot / Cut-to-Length: Available in stocked lengths and sold by the foot, allowing contractors and facility managers to order precisely the quantity needed for single doors or multi-door projects.
- Commercial Door Bottom Sealing: Installs on the bottom face or surface of a door to close the gap between door bottom and threshold or floor, helping control air infiltration, dust, insects, and sound transmission in commercial openings.
- Pemko Trusted Quality: Pemko is a recognized manufacturer of commercial door hardware and sealing products; the 307BSPV is part of their established door bottom sweep line.
Technical Details
| Feature | Details |
|---|---|
| Brand | Pemko |
| Part Number | 307BSPV |
| Part Type | Door Bottom Sweep |
| Channel Height | 7/8" Aluminum Channel |
| Insert Width | 1" Vinyl Insert |
| Insert Material | Replaceable Vinyl |
| Finish / Color | Black Suede Powder (BSP) |
| Channel Material | Aluminum |
| Sold By | By the foot; cut to stocked lengths shown |
| BHMA Certification | Not BHMA certified |
| Application | Commercial door openings |
Documentation
| Brand | Pemko |
| Length | 36 Inch |
| Material Length | 1" |
| Bottom Weatherseal Type | Door Bottom |
| Housing Length | 7/8" |
| Housing Finish | Black Suede Powder Coat |
| Insert Material | Vinyl |
