Sargent 8221 Mortise Deadlock - Cylinder x Thumbturn
SAFETY CAUTION
Deadbolt only functions not recommended for use on any door used for Life Safety egress
The Sargent 8200 Series is a heavy-duty mortise platform for commercial and institutional openings. Certified to and exceeds ANSI/BHMA A156.13, Series 1000, Operational Grade 1 and Security Grade 1. This listing is the Deadlock - Cylinder x Thumbturn function (ANSI/BHMA F17) -- a mortise deadlock: a deadbolt in a mortise case, with no lever and no latchbolt.
Deadlock - Cylinder x Thumbturn Function
How the lock behaves at the opening, stated as the catalog states it, with what each line means in practice.
- A Deadbolt Only -- No Latchbolt: Deadbolt operation only — there is no latchbolt in this lock -- the deadbolt is the only bolt, and the door is secured by throwing it.
- Deadbolt Worked from Outside: Key outside retracts and projects deadbolt — the key throws the deadbolt to secure the opening and withdraws it to release it.
- Deadbolt Turned by Hand Inside: Thumbturn inside retracts and projects deadbolt — the deadbolt is thrown and withdrawn by hand from the inside, with no key needed on that side.
Key Product Features
- ANSI/BHMA Grade: Certified to and exceeds ANSI/BHMA A156.13, Series 1000, Operational Grade 1 and Security Grade 1.
- Cycle testing: Sargent 8200 Series UL Cycle above and beyond test completed at 16 Million Cycles. Verification ID: V584148.
- Lock case: 12 gauge heavy duty wrought steel, zinc dichromate plated. Thickness 7/64" (3mm) (.109").
- Keying: Can be masterkeyed or grand masterkeyed. Construction keying available. LA standard keyway.
- Warranty: 10 year limited mechanical, 5 year limited MELR, 2 year limited electrical. Warranty limited to replacement of lockbody.
Technical Specifications
| Series | Sargent 8200 Series Mortise Deadlock |
| Function | 8221 - Deadlock - Cylinder x Thumbturn |
| ANSI/BHMA function | F17 |
| Deadbolt | Deadbolt is one-piece hardened stainless steel with 1" (25mm) projection |
| Grade | Certified to and exceeds ANSI/BHMA A156.13, Series 1000, Operational Grade 1 and Security Grade 1. |
| Cycle testing | Sargent 8200 Series UL Cycle above and beyond test completed at 16 Million Cycles. Verification ID: V584148. |
| Lock case | 12 gauge heavy duty wrought steel, zinc dichromate plated. Thickness 7/64" (3mm) (.109"). |
| Backset | Backset 2-3/4" (70mm) only. |
| Minimum stile | 4-1/2" (114mm) minimum stile for 7800/8200. |
| Outside front plate | Outside Front Plate Brass, bronze or stainless steel. 8" (203mm) x 1-1/4" (31mm). |
| Front | Front adjustable at any angle from flat to beveled 1/8" (3mm); field adjustable, beveled, armored front, with a .125 inch (3mm) thickness minimum. |
| Inside front | 1/8" (.125") cold-rolled steel inside front holds lock securely in door. |
| Door prep | ANSI/SDI A250.14 modified per template 7057. |
| Cylinder | Brass, size #41 (1-1/8") standard. |
| Cylinder certification | ANSI/BHMA A156.5, Grade 1; 6 pin; Fixed, Interchangeable, Disposable; Available with LFIC and SFIC. |
| Interchangeable core note | LFIC (Removable) Cylinders and SFIC Cylinders do not meet Security Grade 1 requirements. |
| Keys | Two, nickel silver (control key or emergency key must be ordered when required). |
| Keying | Can be masterkeyed or grand masterkeyed. Construction keying available. LA standard keyway. |
| Building standard | Meets BOMA International 4.13.8. |
| Warranty | 10 year limited mechanical, 5 year limited MELR, 2 year limited electrical. Warranty limited to replacement of lockbody. |
| Brand | Sargent |
| Lead time | Factory order: 3-4 weeks |
Ordering & Installation
Door preparation: ANSI/SDI A250.14 modified per template 7057. Backset 2-3/4" (70mm) only. Confirm the stile before specifying: 4-1/2" (114mm) minimum stile for 7800/8200.
We list seven finishes online for this deadlock: 626 Satin Chrome, 630 Satin Stainless, 613 Oil Rubbed Bronze, 613E Oil Rubbed Bronze Equal, 605 Polished Brass, 612 Satin Bronze, 625 Polished Chrome. Cylinder and keyway options listed online are LC - Less Cylinder, LA Keyway, 60 - LFIC less Core, 70 - SFIC less Core. Sargent catalogues more of both -- if you need a finish, cylinder or keyway that is not listed here, or a door thickness other than 1-3/4" (44mm), email sales@doorwaysplus.com and we will quote it.
Keys supplied: Two, nickel silver (control key or emergency key must be ordered when required).
This deadlock is one price in every finish -- Sargent lists it that way on the price book's deadlock page.
| Finish with BHMA code | 626 - US26D Satin Chrome or 630 - US32D Satin Stainless or 613 - US10B Oil Rubbed Bronze or 613E - US10BE Oil Rubbed Bronze Equal or 605 - US3 Polish Brass or 612 - US10 Satin Bronze or 625 - US26 Polish Chrome |
| Sargent Keyways | LC - Less Cylinder or LA Keyway or 60 - LFIC less Core or 70 - SFIC less Core |
| Brand | Sargent |
| Series | Sargent - 8200 Series |
