Sargent 82-5579 Indicator Over-Travel Cam Assembly for 8200 Series Mortise Locks — 38 & 59 Functions (2-1/4" Door Thickness)

The Sargent 82-5579 is a genuine OEM Indicator Over-Travel Cam Assembly designed for Sargent 8200 Series and 7800 Series mortise locks. This precision-machined replacement cam is engineered specifically for doors with a 2-1/4" door thickness and is factory-matched to Functions 38 and 59 — indicator functions that signal room occupancy or vacancy status. As a direct OEM part, the 82-5579 restores the cam mechanism to original Sargent factory specifications, ensuring accurate indicator over-travel operation without the guesswork of aftermarket substitutes.

Institutional Grade Features & Benefits

• Genuine OEM Sargent Component: Factory-manufactured replacement part engineered to exact Sargent tolerances for reliable, long-term performance in 8200 and 7800 Series mortise lock applications.
• Indicator Over-Travel Cam Function: Specifically designed to support the indicator over-travel mechanism used in privacy and occupancy-signaling mortise lock functions, maintaining smooth and accurate operation of the indicator slide.
• Precise Door Thickness Fit: Sized for 2-1/4" door thickness, ensuring correct cam geometry and engagement depth for the specified door preparation.
• Compatible Lock Functions: Engineered for use with Sargent mortise lock Functions 38 and 59.
• Eliminates Indicator Malfunctions: Replaces worn, broken, or misaligned cam assemblies that cause indicator sluggishness, incorrect status display, or over-travel failure.
• Simplifies Maintenance: A single, correctly sourced OEM cam assembly reduces service time and callbacks on indicator-function mortise locks in commercial, institutional, and healthcare facilities.
• Broad Series Compatibility: Fits within the widely deployed Sargent 8200 Series mortise lock platform, one of the most specified heavy-duty mortise lock lines in commercial door hardware.

About Sargent Functions 38 & 59 (Indicator Functions)

Sargent mortise lock Function 38 and Function 59 are indicator-type functions that incorporate a visual occupancy signal — typically a vacant/occupied display visible at the door face — used in restrooms, private offices, dressing rooms, and healthcare spaces. The indicator over-travel cam assembly is a critical internal component that translates the locking or thumbturn action into movement of the indicator slide. A worn or damaged cam directly impairs the indicator's ability to display correct occupancy status.
