Bobrick 1002184 Pilaster Shoe 5"
Bobrick 5" pilaster shoe, factory number 1002184. It covers the base of the pilaster (stile) on a toilet partition. Bobrick's toilet-partition catalog: a one-piece shoe conceals the stile leveling device.
What is this part?
A replacement pilaster shoe, not a finished stall or door. The printed size is 5". Measure the pilaster and order that size. The catalog shoe conceals the stile leveling device at the floor.
How do I confirm I ordered the right SKU?
Match factory number 1002184 and the 5" size on the failed shoe. Nearby sizes: 1002176 is 4"; 1002177 is 6". Do not substitute a different width.
Institutional Grade Features & Benefits
- Size: 5".
- Function: one-piece shoe conceals the stile leveling device (Bobrick toilet-partition catalog).
- Related hardware: clip 1002185; screw 1002189.
- Factory number: 1002184.
- Lead time: 5-15 business days.
Technical Details
| Brand | Bobrick |
| Factory number | 1002184 |
| Part type | Pilaster shoe |
| Size | 5" |
| July row | Shoe 5" |
Which pilaster shoe size?
July 15 2026 prints these factory numbers and sizes. Match the size to the pilaster you are covering.
| Factory number | Size |
| 1002175 | 3" |
| 1002176 | 4" |
| 1002184 | 5" |
| 1002177 | 6" |
| 1002197 | 7" |
| 1002178 | 8" |
| 1002179 | 10" |
| 1002180 | 12" |
| 1002181 | 16" |
| 1002196 | 18" |
| 1002182 | 20" |
| 1002183 | 24" |
Documentation
On the Documents tab: Bobrick Toilet Partition Catalog.pdf.
| Brand | Bobrick |
Bobrick Toilet Partition Catalog.pdf
Download
