PDQ MR211 KJSJ Single Dummy Trim - Grade 1
The PDQ MR211 KJSJ is Single Dummy trim for the PDQ MR Series. It provides fixed, non-operating knob trim -- there is no latch, deadbolt, or operating mechanism -- for the pull side of an opening and to visually match active MR Series mortise locksets on closet doors, storage rooms, and single-side dummy applications.
The Ball Knob (KJ) is solid forged brass with a clean, architectural aesthetic on a J-Series Sectional (round rose) in a US32D (630) Satin Stainless finish.
Function: Single Dummy Trim (no ANSI code)
Single Dummy trim mounts a fixed knob on the pull side of the door with no operating mechanism:
- Rigid outside lever.
Technical Specifications
| Feature | Details |
| Model | PDQ MR211 KJSJ (J-Series Sectional (round rose)) |
| Function | Single Dummy Trim (no ANSI code) |
| Trim Operation | Fixed / Non-operating (single-side dummy trim) |
| Knob Design | Ball Knob (KJ) |
| Trim / Mounting | J-Series Sectional (round rose) (round rose) |
| Base Finish | US32D (630) Satin Stainless -- 626 not offered (J-Series) |
| Handing | Non-handed (dummy trim; no handing required) |
| Warranty | Limited Lifetime (MR Series) |
Why the PDQ MR Series Dummy Trim
- Aesthetic Match: the same Ball Knob J-Series trim used on the active MR Series locksets, for a consistent look across active and inactive door leaves.
- Solid Forged Brass: a durable forged-brass knob finished in US32D Satin Stainless; premium architectural finishes (605, 606, 612, 613E, 622, 629) are also available.
Finish availability: This J-Series dummy trim is offered in 630 (US32D Satin Stainless) as the base finish, plus premium architectural finishes 605, 606, 612, 613E, 622, 629. It is not offered in 626 (626 is an F-Series finish).
*Ball knobs are not ADA compliant. The KJ ball knob does not meet ADA/ICC A117.1 operable-hardware requirements (no tight grasping/pinching/twisting). For ADA-governed openings, specify a lever trim.
| Finish with BHMA code | 630 - US32D Satin Stainless or 613E - US10BE Oil Rubbed Bronze Equal or 605 - US3 Polish Brass or 606 - US4 Satin Brass or 612 - US10 Satin Bronze or 622 - US19 Flat Black or 629 - US32 Polish Stainless |
| Brand | PDQ |
| ANSI Mortise Lock Function | Dummy Trim |
| Trim Design | KJSJ |
| Series | PDQ - MR Series |
| Strike Type | 4-7/8 ANSI Strike - Hollow Metal Frames |
