PDQ MR211 BJSR Square Rose Single Dummy Trim - Grade 1
The PDQ MR211 BJSR is Single Dummy trim for the PDQ MR Series. It provides fixed, non-operating lever trim -- there is no latch, deadbolt, or operating mechanism -- for the pull side of an opening and to visually match active MR Series mortise locksets on closet doors, storage rooms, and single-side dummy applications.
The Boston (BJ) lever is solid forged brass with a clean, architectural aesthetic on a J-Series Sectional (square rose) in a US32D (630) Satin Stainless finish. Its "return-to-door" design is ADA compliant and helps prevent clothing, bags, or straps from snagging on the hardware in busy corridors.
Function: Single Dummy Trim (no ANSI code)
Single Dummy trim mounts a fixed lever on the pull side of the door with no operating mechanism:
- Rigid outside lever.
SR Square Rose Trim
This is the SR square-rose version. The PDQ MR Series price list (effective March 3, 2025, page 13, "J Series Rose and Escutcheon Lock Adjustment") lists the J-Trim sectional rose in two shapes:
- SJ -- Sectional Round Rose - J Trim: no charge.
- SR -- Sectional Square Rose - J Trim: $20.00 lock adjustment.
Page 13 marks the square rose J-Trim only -- it is not offered on F-Trim. SR is a lock adjustment to the same lock, so the function and lock body are unchanged; the rose shape changes.
Technical Specifications
| Feature | Details |
| Model | PDQ MR211 BJSR (J-Series Sectional (square rose)) |
| Function | Single Dummy Trim (no ANSI code) |
| Trim Operation | Fixed / Non-operating (single-side dummy trim) |
| Lever Design | Boston (BJ) |
| Trim / Mounting | J-Series Sectional (square rose) (square rose) |
| Base Finish | US32D (630) Satin Stainless -- 626 not offered (J-Series) |
| Rose Shape | Sectional Square Rose (SR) -- J-Trim only |
| Handing | Non-handed (dummy trim; no handing required) |
| Warranty | Limited Lifetime (MR Series) |
Why the PDQ MR Series Dummy Trim
- Aesthetic Match: the same Boston J-Series trim used on the active MR Series locksets, for a consistent look across active and inactive door leaves.
- ADA-Compliant Lever: the "return-to-door" lever design meets accessibility requirements.
- Solid Forged Brass: a durable forged-brass lever finished in US32D Satin Stainless; premium architectural finishes (605, 606, 612, 613E, 622, 629) are also available.
Finish availability: This J-Series dummy trim is offered in 630 (US32D Satin Stainless) as the base finish, plus premium architectural finishes 605, 606, 612, 613E, 622, 629. It is not offered in 626 (626 is an F-Series finish).
| Finish with BHMA code | 630 - US32D Satin Stainless or 613E - US10BE Oil Rubbed Bronze Equal or 605 - US3 Polish Brass or 606 - US4 Satin Brass or 612 - US10 Satin Bronze or 622 - US19 Flat Black or 629 - US32 Polish Stainless |
| Brand | PDQ |
| ANSI Mortise Lock Function | Dummy Trim |
| Trim Design | BJSR |
| Series | PDQ - MR Series |
| Strike Type | 4-7/8 ANSI Strike - Hollow Metal Frames |
