NGP SLAL-125-BF4DR Aluminum Bi-Fold Track Set for 4 Doors, 125 lb
The National Guard Products SLAL-125-BF4DR is the four-door aluminum bi-fold, top-mount kit: folding doors up to 36 inch wide and 125 lb each, 1-3/8 to 1-3/4 inch thick, commercial, ADA push force. The complete kit includes one track, two top pivots, two bottom pivots, two rollers, two snuggers, two aligners, two wood knobs, and six chrome hinges.
Lengths on this listing: 48, 60, and 72 inch. 96 inch and 144 inch (factory '2 at 72 inch') are not listed. The 2-door kit is SLAL-125-BF2DR. NGP does not print a BHMA Grade 1 claim on this factory page.
Institutional Grade Features & Benefits
- Designed for Commercial Applications
- For Use with 1-3/8" To 1-3/4" Thick Doors
- For Folding Doors up to 36" Wide and up to 125 lbs. Each
- Meets ADA Push Force Requirements
- 5-Year Warranty
- Track lengths on this listing: 48, 60, and 72 inch (96 inch and 144 inch not listed)
- Four-Door Complete Kits Include: (1) Track, (2) Top Pivots, (2) Bottom Pivots, (2) Rollers, (2) Snuggers, (2) Aligners, (2) Wood Knobs, (6) Chrome Hinges
Standards
Technical Details
| Model | SLAL-125-BF4DR |
| Type | Bi-fold track set, 4 doors |
| Manufacturer | National Guard Products |
| Description | Aluminum Bi-Fold, Top Mount, Four Door Track System |
| Capacity | 125 lb per door (NGP factory) |
| Lengths on this listing | 48, 60, and 72 inch |
| Finish | Mill finish aluminum track |
| Door thickness | 1-3/8 inch to 1-3/4 inch |
| Door width | Up to 36 inch (NGP factory) |
| ADA | Meets ADA push force requirements (NGP factory) |
| Warranty | 5-year (NGP factory) |
Ordering and Lead Time
Order by track length. This listing is the 4-door bi-fold kit. Made to order. Lead time: 10-15 business days.
| Length | 48 Inch or 60 Inch or 72 Inch |
| Brand | National Guard Products |
| Trackset Type | Bifold |
| Maximum Weight of Door | 125 Lbs |
