McKinney 1400-MCK 4x4 Five-Knuckle Full Mortise Plain Bearing Butt Hinge — Residential Weight
McKinney 1400-MCK 4 x 4 five-knuckle residential weight plain bearing hinge.
Lead time: Normally ships in 2-3 business days via McKinney QuickShip; current lead time confirmed at order acknowledgment.
Tags :
McKinney 1400 Series 4x4 Five-Knuckle Full Mortise Plain Bearing Butt Hinge — Residential Weight
The McKinney 1400 is a full mortise, five-knuckle, plain bearing butt hinge designed for light interior residential and light-commercial door applications. Manufactured by McKinney — a trusted name in commercial and residential hardware — this hinge offers reliable, straightforward performance in a classic 4-inch by 4-inch profile. Also commonly referred to as a residential weight plain bearing hinge, the 1400 series is engineered for standard-duty interior doors where a clean mortise installation is preferred. The hinge is field reversible, making it suitable for either hand without requiring a separate part order.
Institutional Grade Features & Benefits
- Full Mortise Installation: Designed to be set flush into routed recesses in both the door edge and the door frame, producing a clean, professional appearance and a tight, stable connection between door and frame.
- Five-Knuckle Construction: The classic five-knuckle barrel configuration provides balanced load distribution along the pin, contributing to smooth, consistent swing performance on light residential and light-commercial interior doors.
- Plain Bearing Design: A plain bearing (non-ball-bearing) pivot interface suits the demands of residential weight doors, offering a cost-effective solution where heavy-traffic or high-frequency swing cycles are not a primary concern.
- Residential Weight Rating: Sized and specified for light interior residential and light-commercial doors — the right choice for standard hollow-core and solid-core interior door applications within its intended weight class.
- Field Reversible: The hinge can be reversed in the field to accommodate either hand of door, eliminating the need to stock separate left-hand and right-hand parts and simplifying job-site inventory.
- 4 x 4 Inch Format: The standard 4" x 4" leaf size is one of the most widely specified butt hinge dimensions for residential and light-commercial interior doors, ensuring broad compatibility with common door and frame preparations.
- McKinney Quality: Backed by McKinney's long-standing reputation in architectural door hardware, the 1400 series delivers dependable day-to-day performance for builders, remodelers, and facility managers alike.
Technical Specifications
- Model Number: 1400-MCK
- Brand: McKinney
- Part Type: Full Mortise Butt Hinge
- Knuckle Count: Five-knuckle
- Bearing Type: Plain bearing (non-ball-bearing)
- Weight Class: Residential weight
- Hinge Size: 4 inch x 4 inch
- Installation Type: Full mortise
- Handing: Field reversible — suits either hand
- Intended Application: Light interior residential and light-commercial doors
Technical Details
| Feature | Details |
|---|---|
| Brand | McKinney |
| Part Number | 1400-MCK |
| Part Type | Full Mortise Butt Hinge |
| Hinge Size | 4 in x 4 in |
| Knuckle Configuration | Five-knuckle |
| Bearing Type | Plain bearing |
| Weight Class | Residential weight |
| Installation Method | Full mortise |
| Handing | Field reversible — either hand |
| Application | Light interior residential and light-commercial doors |
Documentation
| General - US Finishes | US26D - Satin Chrome or US26 - Polished Chrome or BSP - Black Suede Power Coat or US4 - Satin Brass or US10B - Oil Rubbed Bronze or USP - Prime Painted |
| Brand | McKinney |
| Hinge Type | Full Mortise |
| Hinge Mounting | Full Mortise |
| Door Handing | Field Reversible |
| Hinge Height | 4.0" Hi |
| Hinge Width | 4.0" Wi |
| Hinge Grade/Thickness | Residental Wt .085 to .106 |
| Hinge Corners | Square |
| Hinge Knuckle | 5 Knuckles |
| Base Material | Steel |
| Part Type | Hinge, Hinge |
