Hager 3410 AUG Grade 1 Passage Lever Latchset
Function Information:
The Hager 3410 AUG is an industrial-strength cylindrical latchset built for the most demanding high-traffic environments. As a Passage Function (ANSI F75), both levers are always active and free-turning, providing immediate, unhindered access from either side of the door. Featuring the bold, modern August (AUG) lever design, this latchset combines a clean, linear architectural aesthetic with the superior institutional strength of the Hager 3400 Series. It is the premier choice for hospital corridors, university hallways, and commercial office transitions where longevity and ease of use are non-negotiable.
Grade 1 Performance for High-Frequency Use
The Hager 3410 is engineered to exceed the most rigorous industry benchmarks. Certified to ANSI/BHMA Grade 1, it is tested to withstand over one million cycles, ensuring it can handle the constant abuse of 24/7 facilities. The heavy-duty internal spring cages are specifically designed to prevent lever sag, keeping the August lever perfectly level and aesthetically sharp even after decades of service.
Rugged Construction and ADA Accessibility
Built with a heavy-gauge steel chassis and a zinc dichromate finish for maximum corrosion resistance, the 3410 AUG is designed to perform in harsh commercial settings. The August lever is fully ADA compliant, providing a straight-profile grip that is easily operated by all users without the need for tight grasping or twisting. To ensure a sleek, professional finish and deter vandalism, this latchset features no exposed mounting screws and utilizes a secure thru-bolt installation for a rigid, permanent bond to the door.
Technical Specifications
| Feature | Specification |
| Series | Hager 3400 Series |
| Function | Passage (ANSI F75) |
| Grade | ANSI/BHMA A156.2 Grade 1 (Heavy Duty) |
| Lever Style | August (AUG) |
| Locking | None (Levers Always Active) |
| Chassis | Cylindrical, Steel (Zinc Dichromate Treated) |
| Door Thickness | 1-3/8" to 2" (35 mm - 51 mm) |
| Backset | 2-3/4" (Standard) or 2-3/8" (Optional) |
| Strike | 1-1/4" x 4-7/8" ASA Strike (Standard) |
| Fire Rating | UL/cUL Listed up to 3 hours |
| Accessibility | ADA Compliant (ANSI A117.1) |
Key Product Highlights
- August Modern Design: The AUG lever provides a contemporary, professional look that coordinates perfectly with modern executive and institutional interiors.
- Grade 1 Durability: Specifically engineered for the highest traffic applications, providing a significant return on investment through reduced maintenance.
- Vandal-Resistant Chassis: The integrated thru-bolt design and concealed fasteners provide a robust barrier against hardware tampering and accidental loosening.
- Code-Compliant Safety: UL/cUL listed for 3-hour fire doors, fulfilling the critical building and life-safety codes required for commercial projects.
| Finish with BHMA code | 626 - US26D Satin Chrome or 613 - US10B Oil Rubbed Bronze or 605 - US3 Polish Brass or 606 - US4 Satin Brass or 625 - US26 Polish Chrome |
| Brand | Hager |
| ANSI Cyl Lock Function | F75 - Passage |
| Trim Design | AUG- August |
| Series | Hager - 3400 Series |
