Hager 8229-02H/05LR Touchless Wave Actuator — 4.5" Square Plate with Light Ring, US32D Finish

The Hager 8229-02H/05LR is a hardwired, touchless Wave to Open actuator designed for hands-free activation of low-energy automatic door operators. Featuring a 4.5-inch square plate, an illuminated light ring for visual status feedback, and a satin stainless steel finish (US32D / Black), this actuator is engineered for hygienic, ADA-compliant openings in healthcare facilities, educational buildings, government offices, and high-traffic public spaces where touchless entry is a code or infection-control requirement.

The 8229-02H/05LR pairs with Hager 8300-series low-energy power operators, providing a clean, coordinated access solution from a single manufacturer. The wave symbol graphic on the face plate communicates the touchless activation method intuitively to building users — no instruction signage required.

Key Features & Benefits

• Touchless Hands-Free Activation: Wave-symbol sensor triggers door open cycle without physical contact — critical for infection control in healthcare and food-service environments.
• Illuminated Light Ring: Built-in status light ring provides clear visual indication that the actuator is active and the automatic door system is operational.
• 4.5" Square Hardwired Plate: Robust plate format suits standard commercial door frame and wall mounting locations; hardwired connection for reliable, battery-free performance.
• Satin Stainless Finish (US32D): Corrosion-resistant US32D satin stainless coordinates with stainless hardware throughout the opening and withstands high-cleaning-frequency environments.
• Designed for Hager 8300-Series Operators: Factory-matched to Hager low-energy power operators for simplified specification, installation, and support.
• ADA-Compliant Application: Supports hands-free, accessible door activation consistent with ADA and ICC A117.1 accessible means of egress requirements when used with a compliant low-energy operator.

Typical Applications

• Hospital corridors, exam rooms, and patient care areas requiring hands-free hygienic access
• School and university main entries with ADA accessible automatic door systems
• Government and municipal buildings with low-energy operator installations
• Retail and commercial lobbies specifying touchless Wave to Open entry
• Restroom and utility corridor automatic door openings in high-traffic facilities

Technical Details
