Hager 8229-02H/03LR Touchless Wave Actuator with Light Ring — 4.5" Square, US32D

The Hager 8229-02H/03LR is a hardwired, 4.5-inch square touchless wave actuator combining wheelchair-accessible push-button activation (02H) with hands-free "Wave to Open" technology (03LR) and an illuminated status light ring. Finished in US32D (satin stainless / black), this unit is designed to work with Hager 8300-Series low-energy power operators, making it an ideal access-control input device for ADA-compliant automatic door openings in healthcare, education, government, and high-traffic public facilities.

The touchless wave sensor eliminates the need for physical contact with the actuator plate — a key advantage in hygienic environments such as hospitals, clinics, food-service facilities, and restrooms. The integrated light ring provides a clear visual status indicator, helping building occupants quickly identify the actuator and confirm activation.

Key Features & Benefits

• Hands-Free "Wave to Open": Infrared wave sensor detects hand motion and signals the low-energy operator to open — no touch required, supporting infection-control protocols and hygienic facility management.
• Wheelchair-Accessible Push Button (02H): Combines touchless wave with a hardwired push-button function for users who prefer or require direct activation, meeting ADA accessibility requirements.
• Illuminated Light Ring (03LR): Built-in status light ring provides clear visual feedback of actuator state, improving usability in corridors, lobbies, and vestibules.
• 4.5" Square Hardwired Plate: Substantial plate size ensures high visibility and easy targeting for all users, including wheelchair users per ADA mounting guidelines.
• US32D Finish: Satin stainless / black finish coordinates with contemporary commercial door hardware packages and resists corrosion in high-traffic environments.
• Hager 8300-Series Operator Compatible: Engineered as a matched input device for Hager low-energy automatic door operators — simplifies specification and ensures reliable system integration.

Typical Applications

• Hospital corridors, patient rooms, and clinical spaces requiring touchless, hygienic door activation
• ADA-compliant automatic door systems in schools, universities, and government buildings
• Public restrooms, cafeterias, and food-service facilities
• Office building lobbies and vestibules with low-energy swing door operators
• Retail and commercial entries specifying hands-free "Wave to Open" accessibility hardware

Technical Details
