Adams Rite Steel Hawk 4300 Electrified Deadlatch
The Adams Rite Steel Hawk 4300 is a non-handed, narrow-stile electrified deadlatch for aluminum entrance doors. It is fail secure only. Apply voltage, turn a key, or operate the handle or paddle to release the spring-loaded latchbolt. Egress from the inside by handle or paddle does not depend on power. Entry is by a keyed mortise cylinder or an access-control device. UL 294 Listed.
How to Order
Specify backset, strike, and finish. Monitoring is optional. The lock is non-handed, so there is no hand digit. Lips 17 and 21, and the RITE Pack, are related products ordered separately.
- Backset: 31/32 inch (2), 1-1/8 inch (3), or 1-1/2 inch (4).
- Monitoring: 0 none, or M Form C latch-status monitor.
- Strike: 101 surface-mount 4304 with flat / standard jamb. 201 mortised 4901-01, 4-5/8 inch, flat / standard jamb. 202 mortised 4901-02 radius for pairs of doors. Extended lips for center-hung or thick doors are accessory strikes.
- Finish: 628 Clear Anodized, 313 Dark Bronze Anodized, or 335 Black Anodized.
What Ships
- Strike plate, flat faceplate, and radius faceplate, plus mounting screws.
- 4581 universal cam plug for the specified handle or paddle. Cylinder, paddle, and handle are separate.
- Both flat and radius faceplates are supplied. A flat faceplate can be adjusted in the field for a right or left beveled edge. Faceplate size is 1 inch by 6-7/8 inch.
- The 4600M monitoring switch cannot be used with the 4300.
Technical Details
| Feature | Details |
|---|---|
| Operation | Fail secure only. Continuous duty. 12, 16, or 24 VDC, field selectable. |
| Current | 0.44 A at 12 VDC; 0.458 A at 16 VDC; 0.23 A at 24 VDC. 16 VDC requires adapter VA 7400-16VDC. |
| Connector | Quick-connect plug-in. |
| Handing | Non-handed body. |
| Door | 1-3/4 inch minimum. Interchangeable with MS deadlocks and 4500 / 4900 deadlatches without stile modification. |
| Cylinder | 1 inch length, 1-5/32 inch diameter mortise cylinder with MS cam, such as the 4036, either or both sides. 4066 thumbturn is separate. |
| Case | Steel, corrosion-resistant plating. 15/16 inch by 5-13/16 inch. Depth varies by backset. |
| Latchbolt | Stainless, 5/8 by 1 by 5/8 inch throw. All-metal auxiliary bolt deadlocks the latch against loiding. |
| Listing | UL 294 Listed. |
RITE Pack is a separate package: the deadlatch plus two flat faceplates and two radius faceplates, one each of 628 and 313. Monitoring is not available on the RITE Pack.
| Finish with BHMA code | 628 - Clear Anodized Aluminum or 313 - Dark Bronze Anodized or 335 - Black Anodized |
| Backset | 31/32" Backset or 1-1/8" Backset or 1-1/2" Backset |
| Deadlatch Strike | 101 - Surface Mount 4304 or 201 - Mortised 4901-01 or 202 - Mortised 4901-02 |
| Latchbolt Monitoring | 0 - None or M - Form C Latch Status Monitor |
| Brand | Adams Rite |
| Series | Adams Rite - Deadlatches |
| Fail Safe/Fail Secure | Fail Secure |
| Voltage | 12/16/24 VDC |
