Sargent 7U65 LL Privacy Function, Cylindrical Latchset
Function Information:
The Sargent 7U65 LL is a professional-grade Grade 2 Cylindrical Privacy Latchset engineered to deliver superior performance in high-use commercial and institutional environments. Part of the versatile Sargent 7-Line Series, this latchset is specifically designed for restroom doors in offices, medical facilities, government buildings, and public spaces where a balance of personal privacy and rapid installation is required. Packaged with the 808 Curved Lip ANSI Strike facilitating seamless integration into commercial hollow metal frames.
Performance That Exceeds Standards
The Sargent 7-Line is built to outperform the baseline requirements for Grade 2 hardware. While standard commercial locks meet the minimum, Sargent engineered the 7U65 to provide a "heavy-duty feel" in a standard-duty footprint:
- Superior Cycle Life: This latchset significantly exceeds ANSI/BHMA A156.2 Grade 2 cycle requirements, ensuring years of maintenance-free operation in high-traffic restrooms.
- Rapid Installation: Engineered for efficiency, the 7U65 can be installed in one minute or less, drastically reducing labor costs for large-scale facility upgrades.
- Structural Integrity: Internal through-bolts supply maximum strength and stability without requiring additional door preparation or drilling.
- 5-Year Warranty: Backed by a 5-year limited warranty with no service required, providing a low total cost of ownership.
Privacy Function & Safety Features (ANSI F76)
The 65 Privacy Function is the premier choice for single-occupant spaces, providing essential privacy while maintaining critical emergency access.
- Push-Button Locking: The exterior lever is locked by pressing the push-button on the interior. This provides immediate privacy for the user.
- Automatic Reset Logic: Rotating the interior lever or closing the door automatically releases the push-button. This prevents accidental lockouts and ensures the door is ready for the next occupant.
- Emergency Access: For life-safety compliance, the exterior lever features an emergency release tool slot, allowing authorized personnel to unlock the door from the outside if a guest requires assistance.
- ADA Compliant LL Lever: The LL design features a linear, ergonomic profile that meets all Americans with Disabilities Act requirements, allowing for operation without tight grasping or twisting.
- Non-Handed Versatility: The universal design ensures the latchset can be installed on both left-hand and right-hand swinging doors, simplifying inventory and installation.
Technical Specifications
| Feature | Details |
| Series | Sargent 7-Line (Cylindrical) |
| Function | 65 Privacy / Bedroom / Bath (ANSI F76) |
| Certification | Exceeds ANSI/BHMA A156.2 - Grade 2 |
| Lever Style | LL Design (Linear / Contemporary) |
| Strike Plate | 808 Curved Lip ANSI Strike / 4-7/8" (Standard for Hollow Metal Frames) |
| Backset | 2-3/4" (Standard Commercial) |
| Handing | Non-Handed (Universal) |
| Door Thickness | 1-3/4" Standard (Adjustable for 1-3/8" with special kit #07-2648) |
| Fire Rating | UL/cUL Listed for 3-Hour Fire Doors |
| Warranty | 5-Year Limited Warranty |
Why Choose the Sargent 7U65 LL?
For facility managers at hospitals, schools, and corporate offices, the Sargent 7U65 LL is a high-value security investment. It provides the architectural continuity of a solid, one-piece cast lever with the mechanical strength of a through-bolted chassis. By choosing the 7-Line, you gain a latchset that is user-friendly for both the installer and the end-user, ensuring reliable privacy for years to come.
Ideal Applications:
- Commercial Restrooms: Durable enough for the daily demands of office and retail traffic.
- Medical Facilities: Easy-to-clean solid levers with emergency override for patient safety.
- Government Buildings: Grade 2 performance that meets strict public building standards.
- Public Changing Areas: A secure, fire-rated solution for private stalls and locker rooms.
| Finish with BHMA code | 626 - US26D Satin Chrome or 613 - US10B Oil Rubbed Bronze or 613E - US10BE Oil Rubbed Bronze Equal or 605 - US3 Polish Brass or 606 - US4 Satin Brass or 612 - US10 Satin Bronze or 625 - US26 Polish Chrome |
| Backset | 2-3/4" Backset or 2-3/8" Backset |
| Brand | Sargent |
| ANSI Cyl Lock Function | F76 - Privacy |
| Trim Design | LL |
| Series | Sargent - 7 Line |
| Occupancy Indicator | No |
