Sargent 24-29-6G05 OB Office Knob Lockset

Function Information:

The Sargent 24-29-6G05 OB is a professional-grade Grade 2 Cylindrical Classroom Knob Lockset engineered for reliability in medium-traffic educational and commercial environments. As a cornerstone of the Sargent 6-Line Series, this lockset is designed for doors where key-controlled security is paramount. The 24-prefix indicates this unit is UL Listed for 3-hour fire doors, while the 29-prefix specifies the inclusion of the 2-3/4" backset and #808 ANSI Strike, making it the industry standard for commercial hollow metal frames.

Professional Classroom Security (ANSI F84)

The 05 Classroom Function (often categorized with the G37 logic in the 6-Line series) provides administrative personnel with total control over corridor access while prioritizing life safety.

• Keyed Exterior Control: The outside knob is locked or unlocked exclusively by a physical key. This ensures that unauthorized individuals cannot change the locking status of the door from the corridor.

• Fail-Safe Interior Egress: The inside knob is always free for immediate exit. Occupants can never be locked inside the room, ensuring 100% compliance with NFPA 101 Life Safety codes.

• Deadlocking Protection: Features a deadlocking latchbolt that prevents "shimming" or unauthorized manipulation with tools when the door is closed.

• Classic OB Design: The OB Ball Knob offers a timeless architectural profile with a comfortable, ergonomic grip that has been a standard in institutional hardware for decades.

Built for Institutional Durability

The Sargent 6-Line is recognized as a "standard duty" lock that performs with institutional strength, offering a cost-effective alternative to Grade 1 hardware without sacrificing security.

• Exceeds Grade 2 Standards: Certified to ANSI/BHMA A156.2 Series 4000 Grade 2, this series is tested for hundreds of thousands of cycles to ensure long-term service in schools and offices.

• Corrosion-Resistant Chassis: The internal mechanism is constructed of high-strength steel with zinc dichromate plating, protecting the lock from internal rust and environmental wear.

• Fire-Rated Integrity: With the 24-prefix, this lockset is UL/cUL Listed for use on 3-hour fire-rated doors, making it a code-compliant choice for commercial hallways.

• Sargent LA Keyway: Supplied with the industry-standard 6-pin LA Keyway cylinder, allowing for seamless integration into existing facility master key systems.

Technical Specifications

Why Choose the Sargent 24-29-6G05 OB?

For contractors and facility managers, the Sargent 24-29-6G05 OB represents a high-value security investment. It provides the durability required for K-12 classrooms and municipal offices while maintaining a classic aesthetic. By utilizing the 6-Line Series, you ensure a professional installation that meets all fire and safety codes at a competitive price point.

Ideal Applications:

• K-12 Classrooms: Giving teachers secure control over corridor access.
• Municipal Offices: Professional aesthetics with Grade 2 durability for public buildings.
• Training Rooms: Ensuring sensitive areas are keyed but always safe for emergency exit.
• Commercial Storage: A fire-rated, keyed solution for administrative corridors.
