Sargent 68-2486 Chassis Assembly for 8300 Series Exit Device — LHRB
The Sargent 68-2486 is an OEM replacement Chassis Assembly engineered for the Sargent 80 Series exit device platform, specifically compatible with the 8300 model designation. This core operating chassis is the mechanical heart of the exit device: when the push bar is depressed, the push rail transfers force directly to this chassis assembly, which retracts the latch bolt to allow immediate, code-compliant egress. Handing for this chassis is LHRB (Left Hand Reverse Bevel). Sourced as a genuine Sargent part, the 68-2486 is the correct OEM chassis replacement for restoring proper exit device operation without compromising the integrity of the original hardware installation.
Institutional Grade Features & Benefits
- OEM Sargent Replacement Part: Ensures precise fit, function, and longevity within the 80 Series exit device system — no modifications or adapters required.
- Core Latch Retraction Mechanism: Directly receives force from the push rail when the push bar is actuated, reliably retracting the latch bolt to permit egress.
- 80 Series Platform Compatibility: Designed and verified for use with Sargent 8300 series exit devices, maintaining original device performance specifications.
- LHRB Handing: Configured for Left Hand Reverse Bevel door applications — verify door hand before ordering.
- Restores Exit Device Operation: Ideal for facility maintenance, renovation, and repair projects where the chassis assembly requires replacement due to wear or damage.
- Genuine Sargent Manufacturing Standards: Built to the same tolerances and materials as original production hardware, supporting long-term reliability in high-traffic commercial and institutional door applications.
Technical Specifications
- Compatible Exit Device Model: Sargent 8300 (80 Series)
- Handing: LHRB
- Part Type: Chassis Assembly
- Part Number: 68-2486
- Brand: Sargent
- Product Class: Exit Device Replacement Part
Technical Details
| Feature | Details |
|---|---|
| Model Number | 68-2486 |
| Part Type | Chassis Assembly |
| Handing | LHRB (Left Hand Reverse Bevel) |
| Series Compatibility | Sargent 80 Series |
| Exit Device Compatibility | Sargent 8300 |
| Brand | Sargent |
Door Handing Reference
Parts List Illustration
| Brand | Sargent |
| Series | Sargent - 80 Series |
| Part Type | Chassis Assembly |
