Pemko 325XGSSWSPN Extreme Gap Door Bottom Sweep — White Suede (WSP) with Neoprene Insert
The Pemko 325XGSSWSPN is a commercial-grade door bottom sweep engineered specifically for excessive-gap door openings where standard door bottom seals fall short. Designed for use on fire-rated door assemblies up to 1-1/2 hours, this extreme gap sweep addresses door and frame clearances that exceed the thresholds defined by NFPA 80 — making it an essential compliance solution for fire door assemblies with larger-than-standard undercuts. The 325XGSSWSPN features a surface-mounted, screw-applied U-channel carrier finished in White Suede (WSP) with a field-replaceable neoprene seal insert, combining long-term serviceability with a clean, professional appearance. It is independently fire-tested through Intertek (Warnock Hersey listed) to Intertek IS47 as an excessive-gap solution — providing documented, third-party verification for AHJ (Authority Having Jurisdiction) submittals and fire door inspections.
Institutional Grade Features & Benefits
- Excessive-Gap Fire Door Solution: Purpose-built to address door-bottom clearances that exceed NFPA 80 maximums, restoring code compliance on rated door openings without costly door or frame modifications.
- Fire-Rated Door Compatibility: Independently fire-tested for use with rated door assemblies up to 1-1/2 hours, supporting compliance on the most common commercial and institutional fire door ratings.
- Intertek / Warnock Hersey Listed: Tested to Intertek IS47 — provides a recognized third-party listing for fire door inspection reports, building department submittals, and insurance documentation.
- Surface / Screw-Mount U-Channel: Straightforward installation on the face of the door bottom; no mortising or special tooling required, reducing installation labor on new construction and retrofit projects alike.
- Replaceable Neoprene Insert: The neoprene seal insert is field-replaceable, extending the service life of the U-channel carrier and reducing long-term maintenance costs in high-traffic commercial environments.
- White Suede (WSP) Finish: A neutral, low-glare finish that coordinates with painted hollow metal doors and frames common in healthcare, education, and institutional facilities.
- NFPA 80 Compliance Support: Specifically engineered to bring excessive-gap fire door openings into conformance with NFPA 80 requirements for door and frame clearances on fire-rated assemblies.
Applications
- Commercial and institutional fire-rated door assemblies with excessive bottom clearances
- Retrofit and renovation projects requiring NFPA 80 excessive-gap compliance
- Healthcare, education, government, and hospitality facilities with hollow metal door and frame systems
- Projects requiring documented Intertek / Warnock Hersey fire-test listings for AHJ approval
- Any application where the door bottom gap exceeds standard NFPA 80 clearance limits and a listed seal solution is required
Technical Details
| Feature | Details |
|---|---|
| Brand | Pemko |
| Model / Part Number | 325XGSSWSPN |
| Part Type | Door Bottom Sweep (Extreme Gap) |
| Finish / Color | White Suede (WSP) |
| Seal / Insert Material | Neoprene (replaceable insert) |
| Mounting Method | Surface / screw-mount U-channel |
| Fire Rating Compatibility | Rated door assemblies up to 1-1/2 hours |
| Listing / Test Standard | Intertek (Warnock Hersey) listed — tested to Intertek IS47 |
| Application Standard | Excessive-gap solution for door and frame clearances exceeding NFPA 80 |
Documentation
| Length | 36 Inch or 48 Inch |
| Brand | Pemko |
| Bottom Weatherseal Type | Door Bottom |
| Housing Finish | White Suede |
| Weatherstripping Type | Perimeter Gasketing |
| Fire Rated | Fire Rated |
| Insert Material | Neoprene |
| Mounting Type | Surface Mounted |
| Sweeps, Door Bottom or Rain Drip | Door Bottom |
