Pemko 2343AV Hospitality Door Bottom Shoe - Aluminum Finish
The Pemko 2343AV is a specialized Hospitality Door Bottom Shoe engineered to solve the unique challenge of balancing airflow with privacy. Designed specifically for hotel guest rooms, multi-family housing, and suites, this door shoe utilizes a unique notched fin vinyl insert that allows for up to 50% free airflow. This ensures that bathroom exhaust fans and HVAC systems can pull return air from the hallway while the offset "V" pattern of the insert blocks light leakage and reduces noise transmission.
High-Performance & Privacy Features
- Airflow-Friendly Design: The Eco-V Notched Fin Insert allows air to circulate under the door, preventing negative pressure in rooms while maintaining a secure visual barrier.
- Light and Sound Control: Expertly crafted to block disruptive hallway light and muffled sounds, enhancing the guest experience without compromising mechanical ventilation.
- Durable Construction: Features a heavy-duty aluminum channel with a removable and replaceable EV94 black vinyl insert, ensuring long-term performance in high-occupancy environments.
- Life Safety Certified: Rigorously tested for UL 10C Positive Pressure fire safety and UL 1784 smoke leakage, meeting strict building codes for hospitality corridor openings.
- Eco-Friendly Certification: Proudly GREENGUARD Gold Certified for low chemical emissions (V.O.C.), contributing to a healthier indoor environment.
Technical Specifications
- Manufacturer: Pemko (ASSA ABLOY)
- Model Number: 2343AV
- Width: 1-3/16" (30.2 mm)
- Total Height: 11/16" (17.5 mm) with insert
- Finish: Mill Aluminum (A)
- Compatibility: Ideal for doors with a minimum thickness of 1.18 inches.
- Length Availability: 36" (In Stock) | 48" (3-4 week lead time)
- Certifications: BHMA Certified, UL Fire Rated, ANSI: R3D414, R3D415.
| Length | 36 Inch or 48 Inch |
| Brand | Pemko |
| Insert Material | Vinyl |
| Material Length | 11/16" |
| Housing Finish | Aluminum |
| Housing Length | 3/16" |
| Fire Rated | Fire Rated |
| Smoke Rated | Smoke Rated |
| Sound Rated | Sound Rated |
| Bottom Weatherseal Type | Door Bottom |
| Sweeps, Door Bottom or Rain Drip | Door Bottom |
