PDQ MR207 KJEJ Double Dummy with Active Trim - Grade 1
The PDQ MR207 KJEJ is Double Dummy with Active Trim trim for the PDQ MR Series. It provides free-turning (active), non-operating knob trim -- there is no latch, deadbolt, or operating mechanism -- for push/pull applications and to visually match active MR Series mortise locksets on inactive door leaves, closet doors, and the inactive leaf of a pair of doors.
The Ball Knob (KJ) is solid forged brass with a clean, architectural aesthetic on a J-Series Escutcheon in a US32D (630) Satin Stainless finish.
Function: Double Dummy with Active Trim (no ANSI code)
Double Dummy with Active Trim mounts a free-turning (active) knob on both sides of the door with no operating mechanism:
- Movable outside lever.
- Movable inside lever.
Technical Specifications
| Feature | Details |
| Model | PDQ MR207 KJEJ (J-Series Escutcheon) |
| Function | Double Dummy with Active Trim (no ANSI code) |
| Trim Operation | Free-turning / Non-latching (active dummy trim) |
| Knob Design | Ball Knob (KJ) |
| Trim / Mounting | J-Series Escutcheon (escutcheon) |
| Base Finish | US32D (630) Satin Stainless -- 626 not offered (J-Series) |
| Handing | Non-handed (dummy trim; no handing required) |
| Warranty | Limited Lifetime (MR Series) |
Why the PDQ MR Series Dummy Trim
- Aesthetic Match: the same Ball Knob J-Series trim used on the active MR Series locksets, for a consistent look across active and inactive door leaves.
- Solid Forged Brass: a durable forged-brass knob finished in US32D Satin Stainless; premium architectural finishes (605, 606, 612, 613E, 622, 629) are also available.
Finish availability: This J-Series dummy trim is offered in 630 (US32D Satin Stainless) as the base finish, plus premium architectural finishes 605, 606, 612, 613E, 622, 629. It is not offered in 626 (626 is an F-Series finish).
*Ball knobs are not ADA compliant. The KJ ball knob does not meet ADA/ICC A117.1 operable-hardware requirements (no tight grasping/pinching/twisting). For ADA-governed openings, specify a lever trim.
| Finish with BHMA code | 630 - US32D Satin Stainless or 613E - US10BE Oil Rubbed Bronze Equal or 605 - US3 Polish Brass or 606 - US4 Satin Brass or 612 - US10 Satin Bronze or 622 - US19 Flat Black or 629 - US32 Polish Stainless |
| Rose / Escutcheon Style | Standard Escutcheon - EJ or Wide Escutcheon - EW |
| Brand | PDQ |
| ANSI Mortise Lock Function | Dummy Trim |
| Trim Design | KJEJ |
| Series | PDQ - MR Series |
| Strike Type | 4-7/8 ANSI Strike - Hollow Metal Frames |
