NGP L-FRA100-SP Low Profile Lite Frame — 1-3/8" Door, Frame Only
The NGP L-FRA100-SP is a low-profile, 18-gauge cold-rolled steel door window lite frame engineered for commercial hollow metal and wood doors that are 1-3/8" thick. Built on NGP's L-FRA100 low-profile steel frame platform, this SP frame keeps the same mitered-and-welded construction while fitting the thinner door and the printed 1-3/8" glass and glazing-tape combinations. This listing is the frame only — glass is not included. Specify glass thickness on the order.
1-3/8" Door — What It Means for Your Application
Standard L-FRA100 frames are made for 1-3/4" doors with 3/16", 1/4", or 5/16" glass. This listing is the SP frame for a 1-3/8" door. A typical 1-3/8" door takes 1/4" glass with GT-118 (Glazing Tape 1/8"). The other printed 1-3/8" pairs are 3/8" glass with GT-114 (Glazing Tape 1/4") and 1/2" glass with GT-316 (Glazing Tape 3/16"). NGP only ships the combinations shown. Choose visual size and finish on this page, then tell us the glass thickness at order.
Typical Applications
- 1-3/8" thick commercial wood or hollow metal doors that cannot take a standard 1-3/4" L-FRA100
- 1-3/8" doors that need 1/4", 3/8", or 1/2" glass with the matching NGP glazing tape
Product Features
- 18 Ga. Cold Rolled Steel
- Mitered and Welded Corners
- Welded Reinforcing Clips at Corners
- Countersunk Mounting Screw-Holes
- Minimum 3" Width or Height, Maximum 88" Width or Height
- #8 Phillips Head SMS
- Available in Uneven and Fractional Sizes
- Gray Primer (GPZ) Powder Coat Finish
- Required Information: Specify Glass Thickness on Order
Standards
- CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
- POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Technical Details
| Model / Series | NGP L-FRA100-SP |
| Manufacturer | National Guard Products |
| Part type | Door window lite frame (glass not included) |
| Door thickness | 1-3/8" |
| Glass | Customer supplied -- specify thickness. Only the 1-3/8" pairs in the combination table. |
| Glazing tape codes | GT-114 = Glazing Tape 1/4"; GT-118 = Glazing Tape 1/8"; GT-316 = Glazing Tape 3/16". Match the combination table. |
| 1-3/8" door + 1/4" glass | GT-118 (Glazing Tape 1/8") |
| 1-3/8" door + 3/8" glass | GT-114 (Glazing Tape 1/4") |
| 1-3/8" door + 1/2" glass | GT-316 (Glazing Tape 3/16") |
| Frame | 18-gauge cold-rolled steel, mitered and welded corners |
| Frame profile | Low profile SP for 1-3/8" doors |
| Corner reinforcement | Welded reinforcing clips at corners |
| Visual sizes on this listing | 4" x 25", 5" x 20", 6" x 30", 10" x 10", 22" x 22", 22" x 28", 22" x 34", 22" x 58" |
| Order size / door cutout | Visual size plus 2" |
| Fasteners included | #8 Phillips head SMS |
| Finish | GPZ gray primer standard; BPR / DKB / Tan at same size price |
| Fire rating | UL10B / CAN/ULC-S104 and UL10C (factory Standards; no UL file number printed) |
1-3/8" Door / Glass / Tape Combinations
This listing is for 1-3/8" thick doors. Only the configurations shown are available. NGP glazing tape codes: GT-114 = Glazing Tape 1/4", GT-118 = Glazing Tape 1/8", GT-316 = Glazing Tape 3/16".
| Door thickness | Glass thickness | NGP tape | Tape means |
|---|---|---|---|
| 1-3/8" | 1/4" | GT-118 | Glazing Tape 1/8" |
| 1-3/8" | 3/8" | GT-114 | Glazing Tape 1/4" |
| 1-3/8" | 1/2" | GT-316 | Glazing Tape 3/16" |
| Visual Size | 4" x 25" or 5" x 20" or 6" x 30" or 10" x 10" or 22" x 22" or 22" x 28" or 22" x 34" or 22" x 58" |
| Finishes Lites and Louvers | BPR - Beige Primer or GPZ - Gray Primer or DKB - Dark Bronze or T - Tan Primer |
| Brand | National Guard Products |
| Fire Rated | Fire Rated |
| Door Thickness | 1-3/8" Dr Thickness |
