McKinney TA5792 5x4-1/2 Three-Knuckle Heavy Weight Beveled-Edge Anchor Hinge | Full Mortise
McKinney TA5792 5 x 4-1/2 three-knuckle heavy weight beveled-edge anchor hinge.
Lead time: Normally ships in 2-3 business days via McKinney QuickShip; current lead time confirmed at order acknowledgment.
Tags :
McKinney TA5792 5x4-1/2 Three-Knuckle Heavy Weight Beveled-Edge Anchor Hinge — Full Mortise
The McKinney TA5792 is a full mortise, three-knuckle heavy weight anchor hinge engineered for demanding commercial door openings where conventional hinges fall short. Designed specifically for beveled-edge doors with a 1/8-in-2-in bevel, the TA5792 features concealed anchor tabs that lock the hinge into the door frame and door edge, delivering exceptional resistance to pull-through and forced entry on high-frequency, high-abuse openings. At 0.190-in. steel leaf thickness, this hinge provides the robust material cross-section that heavy commercial and institutional doors require. The 5 x 4-1/2 inch leaf size suits wide-stile doors and heavyweight door slabs where bearing surface area and load capacity are critical. Also referenced as a heavy duty mortise anchor hinge or beveled-edge full mortise hinge, the TA5792 is a genuine McKinney OEM component built for long-term, low-maintenance performance.
Institutional Grade Features & Benefits
- Three-Knuckle Design: The three-knuckle barrel configuration provides increased pivot stability and a refined architectural profile suited to commercial hollow metal and wood doors on high-traffic openings.
- Concealed Anchor Tabs: Hidden anchor tabs mechanically interlock the hinge leaf with the door and frame, dramatically reducing the risk of hinge pull-out under heavy use, repeated impact, or forced-entry attempts.
- Beveled-Edge Compatibility: The hinge leaf geometry is precision-machined to seat flush and true on doors with a standard 1/8-in-2-in bevel, eliminating rocking, uneven bearing, and premature wear caused by using a flat hinge on a beveled edge.
- Heavy Weight Construction at 0.190-in. Leaf Thickness: The 0.190-in. steel gauge provides the structural rigidity demanded by heavy door slabs, wide-stile frames, and openings subject to constant or forceful cycling.
- Full Mortise Installation: Both the door and frame leaves mortise fully into their respective recesses, producing a clean flush-mounted installation that protects the knuckle and leaves from surface damage and tampering.
- 5 x 4-1/2 Inch Leaf Size: The generously proportioned leaf distributes load across a wider bearing area, reducing stress concentrations at fastener points on demanding commercial openings.
- Genuine McKinney OEM Component: Manufactured to McKinney's full-line catalog specifications, the TA5792 provides a direct, verified replacement or new-construction fit for openings originally specified with McKinney heavy weight anchor hinges.
Technical Details
| Feature | Details |
|---|---|
| Brand | McKinney |
| Part Number | TA5792 |
| Part Type | Hinge — Full Mortise Anchor Hinge |
| Hinge Size | 5 x 4-1/2 in. |
| Knuckle Count | Three-Knuckle |
| Weight Class | Heavy Weight |
| Gauge / Leaf Thickness | 0.190 in. |
| Edge Type | Beveled Edge (1/8 in 2 in bevel) |
| Anchor Feature | Concealed Anchor Tabs |
| Mounting Type | Full Mortise |
| Intended Application | High-frequency, high-abuse openings with beveled-edge doors |
Documentation
- McKinney Catalog / Product Page - TA5792
- This model is a factory option (modified barrel/tip) of the base hinge; the McKinney document library publishes the cut sheet under the base model. The catalog page above carries the option's specification.
| Door Handing | LH or RH |
| Brand | McKinney |
| General - US Finishes | US26D - Satin Chrome |
| Hinge Type | Anchor |
| Hinge Mounting | Full Mortise |
| Hinge Height | 5.0" Hi |
| Hinge Width | 4.5" Wi |
| Hinge Grade/Thickness | Heavy Wt .180 to .190 |
| Hinge Corners | Square |
| Hinge Knuckle | 3 Knuckles |
| Base Material | Steel |
| Part Type | Hinge, Hinge |
