Hager 47KN Night Latch Lever – Grade 1 Standard Duty for 4700 Series
The Hager 47KN Night Latch Knob is a high-security, standard-duty trim designed specifically for use with Hager 4700 Series Exit Devices. This Night Latch Function (ANSI 03) trim—also known as Storeroom Function—ensures that the exterior knob is always locked and rigid. Entry is only permitted via a key, which retracts the latchbolt for immediate access. This makes the 47KN the premier choice for secure storage rooms, mechanical closets, and rear commercial entryways where unauthorized entry must be strictly prevented.
As a BHMA Certified Grade 1 component, the 47KN is built to withstand the rigorous demands of high-traffic institutional environments. The trim features a rugged steel body and a solid brass or stainless steel ball knob, providing a classic tactile feel with industrial-grade mechanical reliability. Its timeless design ensures it fits seamlessly into any architectural setting while maintaining the highest levels of perimeter security.
Secure Access & Precision Engineering
The Hager 47KN is supplied with a conventional Schlage C Keyway cylinder as standard, allowing for easy integration into existing master key systems. To provide a permanent and stable mount on 1-3/4" thick doors, this trim includes thru bolts as standard hardware. This creates a high-strength, through-the-door connection that prevents the knob assembly from loosening, wobbling, or being tampered with over time.
Key Features
- Night Latch Security: Exterior knob is always locked; key retracts the latchbolt for entry (ANSI 03).
- Grade 1 Performance: BHMA certified to meet the highest industry standards for mechanical life and durability.
- Rugged Construction: Steel trim body with a high-quality brass or stainless steel knob assembly.
- Turtle Prep Compatible: Designed for easy installation on standard 2-1/8" cross bore door preparations.
- Non-Handed Design: Fully reversible in the field for use on both left and right-hand swinging doors.
Technical Specifications
| Feature | Specification |
| Model Number | Hager 47KN |
| ANSI Function | 03 (Night Latch / Storeroom) |
| Certification | BHMA Certified Grade 1 (ANSI/BHMA A156.3-2014) |
| Compatibility | Hager 4700 Series Rim and Vertical Rod Devices |
| Cylinder Type | Conventional Schlage C Keyway (Included) |
| Rose Diameter | 3-1/2" (89 mm) |
| Fasteners | Thru Bolts, Wood, and Machine Screws |
| Warranty | 5-Year Limited Manufacturer Warranty |
Available Finish Options
Select the architectural finish at DoorwaysPlus.com that best matches your facility's design:
- Satin Stainless Steel (US32D): The industry standard for corrosion resistance and low maintenance.
- Sprayed Aluminum (ALM): Matches standard clear anodized aluminum storefront frames.
- Sprayed Dark Bronze (DBZ): A classic, professional look for traditional architectural styles.
- Bright Brass (US3): A polished, traditional finish for upscale institutional entries.
| Finish with BHMA code | 689 - Painted, Aluminum or 630 - US32D Satin Stainless or 605 - US3 Polish Brass or 695 - Painted, Stat Dark Bronze |
| Trim Design | WTN - Withnell or ARC - Archer or AUG- August |
| Brand | Hager |
| Series | Hager - 4700 Series |
| Exit Device Trim Function | Storeroom |
| Door Handing | Field Reversible |
